Hongyan 8x4 Dump Truck Hongyan 40 Ton Dump Truck Hongyan Heavy Dump Truck

Product Details

Place of Origin: Hubei, China

Brand Name: sinotruk

Payment & Shipping Terms

Price: CN¥180,767.50/units 1-4 units

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                euro 3 dump truck, euro 3 dump tipper truck


Condition:	New	Steering:	Left
Horsepower:	351 - 450hp	Emission Standard:	Euro 3
Segement:	Heavy Truck	Market Segement:	Engineering Transportation
Engine Brand:	WEICHAI	Fuel Type:	Diesel
Engine Capacity:	> 8L	Cylinders:	6
Gear Box Brand:	FAST	Transmission Type:	Manual
Forward Shift Number:	10	Reverse Shift Number:	2
Maximum Torque(Nm):	1500-2000Nm	Dimensions (L X W X H) (mm):	1040025003600
Cargo Tank Dimension:	7400x2300x1500	Cargo Tank Length:	6.2-8m
Gross Vehicle Weight:	≥30T	Capacity (Load):	41 - 50t
Fuel Tank Capacity:	300-400L	Drive Wheel:	8X4
Passengers:	3	Driver's Seat:	Normal
Rear Camera:	None	Cruise Control:	None
ABS(Antilock Braking System):	None	ESC(Electronic Stability Control System):	None
Touch Screen:	None	Multimedia System:	None
Window:	Automatic	Air Conditioner:	Automatic
Tire Number:	12	After-sales Service Provided:	Online Support, Video Technical Support

Condition:	New
Steering:	Left
Horsepower:	351 - 450hp
Emission Standard:	Euro 3
Segement:	Heavy Truck
Market Segement:	Engineering Transportation
Engine Brand:	WEICHAI
Fuel Type:	Diesel
Engine Capacity:	> 8L
Cylinders:	6
Gear Box Brand:	FAST
Transmission Type:	Manual
Forward Shift Number:	10
Reverse Shift Number:	2
Maximum Torque(Nm):	1500-2000Nm
Dimensions (L X W X H) (mm):	1040025003600
Cargo Tank Dimension:	7400x2300x1500
Cargo Tank Length:	6.2-8m
Gross Vehicle Weight:	≥30T
Capacity (Load):	41 - 50t
Fuel Tank Capacity:	300-400L
Drive Wheel:	8X4
Passengers:	3
Driver's Seat:	Normal
Rear Camera:	None
Cruise Control:	None
ABS(Antilock Braking System):	None
ESC(Electronic Stability Control System):	None
Touch Screen:	None
Multimedia System:	None
Window:	Automatic
Air Conditioner:	Automatic
Tire Number:	12
After-sales Service Provided:	Online Support, Video Technical Support

Hongyan 8x4 Dump Truck Hongyan 40 Ton Dump Truck Hongyan Heavy Dump Truck

hongyan 8x4 dump truck hongyan 40 ton dump truck hongyan heavy dump truck

Products Technical Specification
Brand-Series		HONGYAN-KINGKAN
Chassis Model		CQ3254HMG384E
Emission Standard		Euro3
Fuel type		Diesel
Cabin		KINGKAN Flat Roof,Long Cab
Country of origine		China
Whole vehicle main dimensions (mm)	Overall dimensions (L×W×H)	1040025003600
	Wheel base	1800+3575+1400
	Front overhang	1435
	Rear overhang	2075
	Front /rear tread(mm)	2006/1850
Weight data (kg)	Gross weight (kg)	31000
	Loading weight (kg)	15800
	Curb weight(kg)	15070
Cargo body Description	Crago body dimensions (mm)	740023001600
	Crago body thickness	side 8mm thickness;bottom 10mm thickness
	Lifting System	front hoisting
Whole vehicle main performance	Max. speed (km/h)	80
	Max. grade ability (%)	35
	Approach/Departure(°)	25/15
	Leaf Spring NO.	2003/3/4
Engine	Model	WP10.380E32
	Maximum power	280kw /380hp
		4 stroke direct injection diesel engine
		6 cylinder in-line with water-cooling, turbo-charging and inter-cooling
	Displacement (L)	9726
	Engine Manufacturer	weichai
Clutch	Model	Φ430 Diaphragm Spring
Transmission	Brand and Model	FAST,10JSD160
Transmission	Number of gears	10 forward gears & 2 reverse
Axle	Front Load capacity (kg)	6500/6500
Axle	Rear Load capacity (kg)	18000/18000
Steering	Model	Power assisted
Steering Wheel	left/right hand drive	LHD
Frame	Type	Bottle neck, double chassis
	Dimension (mm)	940-865 (W) 317 (H)
	Section thickness (mm)	8+8
Electric device	Rated voltage	24V
Electric device	Batteries	2 x 12v, 165Ah
oil tank capacity		350 liters Alluminum with lockable fuel cap
Tyres & Quantity		12.00R20 & 12+1
