Product Details
Place of Origin: Hubei, China
Brand Name: sinotruk
Payment & Shipping Terms
Price: CN¥180,767.50/units 1-4 units
Condition: |
New |
Steering: |
Left |
Horsepower: |
351 - 450hp |
Emission Standard: |
Euro 3 |
Segement: |
Heavy Truck |
Market Segement: |
Engineering Transportation |
Engine Brand: |
WEICHAI |
Fuel Type: |
Diesel |
Engine Capacity: |
> 8L |
Cylinders: |
6 |
Gear Box Brand: |
FAST |
Transmission Type: |
Manual |
Forward Shift Number: |
10 |
Reverse Shift Number: |
2 |
Maximum Torque(Nm): |
1500-2000Nm |
Dimensions (L X W X H) (mm): |
8500X2500X3550 |
Cargo Tank Dimension: |
5800x2300x1500 |
Cargo Tank Length: |
5.3-6.2M |
Gross Vehicle Weight: |
20-25T |
Capacity (Load): |
21 - 30T |
Fuel Tank Capacity: |
300-400L |
Drive Wheel: |
6x4 |
Passengers: |
3 |
Driver's Seat: |
Normal |
Rear Camera: |
None |
Cruise Control: |
None |
ABS(Antilock Braking System): |
None |
ESC(Electronic Stability Control System): |
None |
Touch Screen: |
None |
Multimedia System: |
None |
Window: |
Automatic |
Air Conditioner: |
Automatic |
Tire Number: |
11 |
After-sales Service Provided: |
Online Support, Video Technical Support |
Condition: |
New |
Steering: |
Left |
Horsepower: |
351 - 450hp |
Emission Standard: |
Euro 3 |
Segement: |
Heavy Truck |
Market Segement: |
Engineering Transportation |
Engine Brand: |
WEICHAI |
Fuel Type: |
Diesel |
Engine Capacity: |
> 8L |
Cylinders: |
6 |
Gear Box Brand: |
FAST |
Transmission Type: |
Manual |
Forward Shift Number: |
10 |
Reverse Shift Number: |
2 |
Maximum Torque(Nm): |
1500-2000Nm |
Dimensions (L X W X H) (mm): |
8500X2500X3550 |
Cargo Tank Dimension: |
5800x2300x1500 |
Cargo Tank Length: |
5.3-6.2M |
Gross Vehicle Weight: |
20-25T |
Capacity (Load): |
21 - 30T |
Fuel Tank Capacity: |
300-400L |
Drive Wheel: |
6x4 |
Passengers: |
3 |
Driver's Seat: |
Normal |
Rear Camera: |
None |
Cruise Control: |
None |
ABS(Antilock Braking System): |
None |
ESC(Electronic Stability Control System): |
None |
Touch Screen: |
None |
Multimedia System: |
None |
Window: |
Automatic |
Air Conditioner: |
Automatic |
Tire Number: |
11 |
After-sales Service Provided: |
Online Support, Video Technical Support |
hongyan 6x4 25 Ton dump truck 25Ton tipper 25T dump truck
Products Technical Specification | ||
Brand-Series | HONGYAN | |
Chassis Model | CQ3254HTG384 | |
Emission Standard | Euro3 | |
Fuel type | Diesel | |
Cabin | Genlyon short cab with A/C (optional:Genlyon Flat Top Cab) | |
Country of origine | China | |
Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 8275*2500*3550 |
Wheel base | 3800+1400 | |
Front overhang | 1435 | |
Rear overhang | 1675 | |
Front /rear tread(mm) | 2006/1850 | |
Weight data (kg) | Gross weight (kg) | 25000 |
Loading weight (kg) | 12780 | |
Curb weight(kg) | 12090 | |
Cargo body Description | Crago body dimensions (mm) | 5400*2300*1300 |
Crago body thickness | side 6mm thickness;bottom 8mm thickness | |
Lifting System | Middle hoisting | |
Whole vehicle main performance | Max. speed (km/h) | 80 |
Max. grade ability (%) | 35 | |
Approach/Departure(°) | 23/15 | |
Leaf Spring NO. | 9/12 | |
Engine | Model | WP10.340E32 |
Maximum power | 250kw /340hp | |
4 stroke direct injection diesel engine | ||
6 cylinder in-line with water-cooling, turbo-charging and inter-cooling | ||
Displacement (L) | 9.726 | |
Engine Manufacturer | weichai | |
Clutch | Model | Φ430 Diaphragm Spring |
Transmission | Brand and Model | FAST,12JSD160T |
Number of gears | 12 forward gears & 2 reverse | |
Axle | Front Load capacity (kg) | 7500 |
Rear Load capacity (kg) | 18000 | |
Steering | Model | ZF Hydraulic Power Steering |
Steering Wheel | left/right hand drive | LHD |
Frame | Model | 865/317 8+8 |
Electric device | Rated voltage | 24V |
oil tank capacity | 350L | |
Tyres & Quantity | 12.00R20 & 10+1 |
