Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Eaton Fuller 10-speed manual Crane Truck, CT660 Truck Mounted Crane, 3800kg Mobile Crane Truck


Driving Cab Roof:	Flat	Keyword:	Crane Truck Mobile Truck Crane Sizes
Hydraulic Parts:	Telescopic Boom Mobile Crane Made	Tire Number:	6
Passengers:	5	Transmission:	Eaton Fuller 10-speed Manual
Rated Loading Capacity:	8-10 Ton	Marketing Type:	Other
Make:	East Wind	Gross Weights:	14490kg
Feature:	TRUCK CRANE	Model:	CT660
Hydraulic Valve Brand:	Changjiang	Reverse Shift Number:	1
Capacity:	Up To 66,000 Lbs

Driving Cab Roof:	Flat
Keyword:	Crane Truck Mobile Truck Crane Sizes
Hydraulic Parts:	Telescopic Boom Mobile Crane Made
Tire Number:	6
Passengers:	5
Transmission:	Eaton Fuller 10-speed Manual
Rated Loading Capacity:	8-10 Ton
Marketing Type:	Other
Make:	East Wind
Gross Weights:	14490kg
Feature:	TRUCK CRANE
Model:	CT660
Hydraulic Valve Brand:	Changjiang
Reverse Shift Number:	1
Capacity:	Up To 66,000 Lbs

SINOTRUK 6X4 Flat Bed Truck Mounted 10 Tons XCMG Crane

Truck Specifications

Dimension (L×W×H) (unloaded) (mm)	10000×2550×3650
Cargo body size (L×W×H) (mm)	6200×2400×600
Approaching angle/Departure angle (°)	16/14
Overhang (front/rear) (mm)	1500/2734
Wheel base (mm)	4600+1350
Max speed (km/h)	95
Curb weight (kg)	11280
Loading Weight (kg)	19590
Actual loading capacity	20-35T

Engine Specifications

Model	WP10.300E22
Fuel type	Diesel
Displacement (ml) Power (kw)	9726 / 220
Emission standard	EURO Ⅱ
Fuel tank capacity (L)	400

Technical Specifications

Transmission Model	HW19710, 10 forward & 2 reverse
Service brake	Dual circuit compressed air brake
Parking brake	Spring energy, compressed air operating on rear wheels
Steering system	BOSH (LHD)
Front axle	Steering with double T-cross section beam
Rear axle	Cast axle housing, central double reduction with differential locks between axles and wheels

Electrical System

Battery	2×12V/165Ah
Alternator	28V-1500kw
Starter	7.5Kw/24V

Additional Features

Reversing buzzer
Fire Extinguisher
Intercooler protection device

Crane Specifications (Model SQS200)

Max lifting capacity (kg)	8000
Maximum operating radius (m)	14
Maximum lifting height (m)	16
Oil tank capacity (L)	150
Rotation angle	All Rotation
Crane weight (kg)	3800
Installation space (mm)	920
